Description
Data:
Voltage: 12V
Length/width/height: 188 x 100 x 171.5
duty cycle: 55% at 14 bar (200PSI) and 100% at 7 bar (100PSI)
max. working pressure: 14 bar (200PSI)
capacity at 0 bar: 44.7 L/min (12 amps)
capacity at 10 bar: 19.5 L/min (21 amps)
min. ambient temperature: -40° C
max. ambient temperature: 70° C
L=188mm x W=100mm x H=172mm
weight: 3.6 kg
Fill time at 20LTR tank:
0 to 145PSI 7 min. 20 sec.
110 to 145PSI 2 min. 25 sec.
0 to 200PSI 13 min. 25 sec.
165 to 200PSI 3 min. 39 sec.
this product comes with a 1 year warranty
